Roland BRIDGE CAST ONE Dual Bus Streaming Mixer
AED 899.00 Incl. VAT
Create separate audio mixes for yourself and your audience using independent game/chat busses. This allows you to hear optimal in-game audio while your stream receives a balanced, polished mix for improved viewer experience.
Brand : Roland
Delivery : 1-2 Days
Return Policy : 7 Days Sealed
Free Shipping UAE
Same day delivery Dubai
Please rate the products and leave us a review after your purchase.
GTIN: 761294521779
Dual Bus Audio Mixing
Create separate audio mixes for yourself and your audience using independent game/chat busses. This allows you to hear optimal in-game audio while your stream receives a balanced, polished mix for improved viewer experience.
Game Audio Control
Fine-tune game audio with customizable Game EQ presets, a limiter to reduce loud sounds like explosions, and a Balance Mode for easy game/chat volume control—all directly from the mixer or via the BRIDGE CAST app.
Professional Mic Processing
Connect professional XLR microphones with a +75 dB high-gain preamp and phantom power. Enhance vocals with built-in EQ, compression, noise suppression, and voice transformer effects for clean, studio-quality sound.
Monitoring & Customization
Experience 5.1/7.1 virtual surround sound, personalize LED colors, and assign hardware buttons for quick actions. The BRIDGE CAST app adds BGM CAST for royalty-free background music and lets you save complete custom profiles.
Main Features
-
Compact desktop streaming interface with core BRIDGE CAST audio features
-
Powerful 32-bit hardware DSP allows you to dedicate all your computer resources to gaming and streaming
-
Create independent mixes for you and the online audience with dual audio busses
-
USB-C connectivity with Windows and Mac computers, the Sony PlayStation®5 console,* and Nintendo Switch
-
High gain (+75 dB) XLR microphone preamp with phantom power for broadcast-grade mics
-
Mic rehearsal feature for fast and easy audio setup
-
High-quality vocal processing: EQ, compressor, noise suppressor, de-esser, and reverb
-
Headphone jack with a professional high-sensitivity output and support for a headset or inline mic
-
5.1 or 7.1 USB virtual surround sound audio and 10-band EQ**
-
Enhance your gaming performance with five customizable Game Effects presets
-
Game effects limiter to lower loud game sounds
-
Voice transformer effects derived from the Roland VT series
-
Delay function to synchronize audio with video when needed
-
Aux input for playing audio from a smartphone or external device
-
Customize settings and save hardware configurations with the BRIDGE CAST app
-
Add royalty-free background music and sound effects to your streams with BGM CAST, available through the BRIDGE CAST app and Roland Cloud
-
Notes:
*Some audio formats are not supported with PlayStation®5. Visit the Knowledge Base to learn more.
**PlayStation 5 and Nintendo Switch do not support USB Virtual Surround
-
Input Channel:
MIC
AUX
USB CHAT (*1)
USB GAME (Speakers) (*1)
USB MUSIC (*1)
USB SYSTEM (*1)
USB CONSOLE (Speakers) (*2)
(*1) When the USB port connection setting is “PC”
(*2) When the USB port connection setting is “CONSOLE”
-
Output Channel:
LINE OUT
PHONES
AUX (*3)
USB MIC (*4)
USB STREAM (*4)
USB PERSONAL (*4)
USB CONSOLE (Microphone) (*5)
(*3) Microphone audio is output from the CTIA MIC jack
(*4) When the USB port connection setting is “PC”
(*5) When the USB port connection setting is “CONSOLE”
-
Audio Mixing Bus: 2 (STREAM MIX, PERSONAL MIX)
-
Sampling Frequency:
Windows: 44.1 kHz, 48 kHz, 96 kHz
macOS/Other: 48 kHz
-
Signal Processing:
AD/DA: 24 bits
Internal Processing: 32-bit Floating point
-
Effects:
MIC: Voice Changer, Noise Suppressor, Compressor, Equalizer, De-esser, Reverb, Low Cut
CHAT: De-esser, Compressor
GAME/AUX (*6): Equalizer, Limiter, Virtual Surround
STREAM: Delay
(*6) Select with GAME EFFECTS setting
-
Audio File Player:
Number of tracks: 2
Data Formats: WAV (Linear PCM, 48 kHz, 16 bits, stereo/mono)
Maximum Time: 5 seconds/track
-
Input Level:
MIC: -85– -10 dBu (Maximum: +2 dBu)
HEADSET MIC: -58.5– -20.5 dBu (Maximum: -8.5 dBu)
AUX: -10 dBu (Maximum: +2 dBu)
-
Input Impedance:
MIC: 3.4 k ohms
HEADSET MIC: 1.3 k ohms
AUX: 10 k ohms
-
Output Level:
LINE OUT: -4 dBu (Maximum: +8 dBu)
HEADSET: +1 dBu (Maximum: +13 dBu)
HEADSET: 78 mW + 78 mW (32 ohms)
HEADSET: 35 mW + 35 mW (250 ohms)
-
Output Impedance:
LINE OUT: 1 k ohm
HEADSET: 10 ohms
-
Connectors:
MIC jack: XLR type (Phantom power DC 48 V, 6 mA Max)
HEADSET jack: Stereo miniature phone type (CTIA, PLUG-IN power)
AUX jack: Stereo miniature phone type (TRRS)
LINE OUT jack: Stereo miniature phone type (TRS)
USB port: USB Type-C (R) (Audio/MIDI/HID Supported)
-
Power:
USB bus power
* Connect to a USB connector that can supply 5 V, 900 mA or more.
-
Current Draw: 5 V DC, 900 mA
-
Operating System:
Microsoft Windows 10, Windows 11
Apple macOS 12 or later
-
Accessories:
Leaflet “Read Me First”
USB 2.0 Type-C to Type-C Cable (2 m, 6.5 feet)
-
Dimensions (L x W x H): 4.4 x 4.3 x 2.2″ / 11.1 x 10.9 x 5.6 cm
-
Weight: 9.7 oz / 275 g
GTIN
761294521779
