Yamaha HS8
Yamaha HS8 2-way bass-reflex bi-amplified nearfield studio monitor with 8″ cone woofer and 1″ dome tweeter.
- 2-way bass-reflex bi-amplified nearfield studio monitor with 8″ cone woofer and 1″ dome tweeter
- 38Hz – 30kHz (-10dB), 47Hz – 24kHz (-3dB) frequency response
- 75W LF plus 45W HF bi-amp system for high-performance 120W power amplification
- ROOM CONTROL and HIGH TRIM response controls
- XLR and TRS phone jack inputs accept balanced or unbalanced signals
- Packaging single
High-performance drivers and mounting system
The drivers used in the HS series monitors deliver superb audio performance that is considerably enhanced by a sophisticated mounting system. A scientific arrangement of screws and a specially designed mounting ring eliminate unwanted vibration and resonance, letting the speaker realize its full sonic potential, without distortion or coloration. Yamaha selects their magnets to optimize solid low-end response. Tweeter frames use an advanced smooth-contour design that minimizes losses, letting you hear high-frequency details with stunning accuracy. The extra thick tweeter frame also diminishes resonance that can interfere with treble clarity. The bottom line? Smooth, accurate response throughout the audio spectrum. And that translates to better-sounding recordings for you.
| HS8 | ||
|---|---|---|
| Speaker type | 2-way bi-amp powered studio monitor | |
| Frequency response (-10dB) | 38Hz – 30kHz | |
| Frequency response (-3dB) | 47Hz – 24kHz | |
| Components | LF | 8″ cone |
| HF | 1″ dome | |
| Crossover | 2kHz | |
| Output power | 120W (LF:75W, HF:45W) | |
| Input sensitivity | -10 dBu/10k ohms | |
| I/O connectors | XLR3-31 type (balanced), PHONE (balanced) | |
| Indicators | Power ON (White LED) | |
| Power consumption | 60W | |
| Shape | Bass-reflex type | |
| Cabinet material | MDF | |
| Dimensions | W | 250mm (9-13/16″) |
| H | 390mm (15-3/8″) | |
| D | 334mm (13-1/8″) | |
| Net weight | 10.2kg (22.5 lbs.) | |
| Accessories | Owner’s Manual, Power cord | |
| Packaging | Single | |
| Others | LEVEL control (+4dB/center click) , EQ: HIGH TRIM switch (+/- 2dB at HF) / ROOM CONTROL switch (0/-2/-4 dB under 500Hz) | |
| Flying and mounting hardware | – | |
| Options | – | |
